HPE Aruba AP-577 (US)
Stock: n/a
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
HPE Aruba AP-577 (US)
- Wireless access point
- Bluetooth 5.0, 802.11ax
- Bluetooth, Wi-Fi
- Dual Band
| Additional Details | |
|---|---|
| Mfr Part #: | R4H23A |
| SHI Part #: | 40031341 |
| Category: | Wireless access point |
| UNSPSC: | 43222640 |
| Manufacturer: | Hewlett Packard Enterprise |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Wireless access point |
| Description | HPE Aruba AP-577 (US) - Wireless access point - Bluetooth 5.0, 802.11ax - Bluetooth, Wi-Fi - Dual Band |
| Manufacturer | Hewlett Packard Enterprise |
| UNSPSC | 43222640 |
| Main Specifications | |
| Dimensions & Weight / Depth | 22 cm |
| Dimensions & Weight / Height | 13 cm |
| Dimensions & Weight / Weight | 2.1 kg |
| Dimensions & Weight / Width | 23 cm |
| Header / Brand | Aruba |
| Miscellaneous / Product Color | White |
| Networking / Connectivity Technology | Wireless |
| Networking / Data Link Protocol |
|
| Networking / Form Factor | External |
| Networking / Type | Wireless access point |
| Packaged Quantity | 1 |
| Service & Support / Type | Limited lifetime warranty |
| System Requirements / OS Required |
|
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 2 |
| Directivity | Directional |
| Gain Level | 6.4 dBi |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Max Operating Temperature | 65 °C |
| Min Operating Temperature | -40 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Depth | 22 cm |
| Device Type | Wireless access point |
| Height | 13 cm |
| Ruggedized Design | Outdoor |
| Weight | 2.1 kg |
| Width | 23 cm |
| Internet of Things (IoT) | |
| Communications Technology | Bluetooth Low Energy (LE), Zigbee |
| Internet of Things (IoT) Compatible | Yes |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Compliant Standards | CB, UL 2043, FCC, EN 60601-1-2, cTUVus, EN 60601-1-1, CE/EMC, Directive 2014/35/EU, Directive 2014/30/EU, ISED, Directive 2014/53/EU, IEC/EN/UL 60950 |
| Included Accessories | Mounting bracket |
| Networking | |
| Capacity |
|
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6) |
| Encryption Algorithm | SSL, WPA, WPA2, WPA3 |
| Features | Auto-uplink (auto MDI/MDI-X), Deep Packet Inspection (DPI), Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Advanced Cellular Coexistence (ACC), cyclic shift diversity (CSD), MU-MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), High-Throughput (HT) support, Energy-Efficient Ethernet (EEE), Orthogonal Frequency Division Multiplexing (OFDM), 2x2 MIMO technology, Very High Throughput (VHT) support, Orthogonal Frequency Division Multiple Access (OFDMA), Target Wait Time (TWT) |
| Form Factor | External |
| Frequency Band | 2.4 GHz, 5 GHz |
| Line Coding Format | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA |
| Performance |
|
| Spread Spectrum Method | OFDM, DSSS, OFDMA |
| Status Indicators | System, status |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Software / System Requirements | |
| OS Required | ArubaOS, InstantOS |
